Soild Brass Rod Peeling Machine 18.5kw 25.8m/min Automatic Operation

Product Categories
Haibeisi (Xiamen) Import and Export Co., Ltd.
Contact Now

Soild Brass Rod Peeling Machine 18.5kw 25.8m/min Automatic Operation

Brand Name : HBS

Model Number : HSW-01

Certification : ISO,CE

Place of Origin : China

MOQ : ≥1Set

Price : USD1000-30000

Payment Terms : T/T, L/C, D/A, D/P

Delivery Time : 15-20Days

Packaging Details : Plywood packed with export sea standard

Control System : PLC

Material : Brass

Name : Brass Rod Peeling Machine

Operation Mode : Automatic

Power : 19.6KW

Processing Efficiency : 99.9%

Processing Range : φ9-70mm

Speed : 25.8m/min

Voltage : 3800V

Weight : 2800KG

Contact Now

Copper Rod Surface Peeling For Soild Rod Hollow Rod Peeling



Main Technical Parameters

SL SPECIFICATION
1 Max Peeling Length 4.2m
2 Max Peeling Size(Round rod) φ9-φ70mm
3 Max Peeling Size(Hex rod) φ9-φ60mm
4 Max Peeling Size(Square rod) φ9-φ60mm
5 Max System Pressure 200kg/m³
6 Large Chain Speed 25.38m/min
7 Main Motor Power 18.5kw
8 Hydraulic Cylinder Size 45*85*510mm
9 Oil Deposited 125L
10 New Weight 2800kg
11 Dimension(L*W*H) 9600*1300*1300mm



Description&Characteristic

copper rod surface peeling machine is a specialized industrial equipment used to remove the outer layer or surface of copper rods. The process of peeling involves removing the oxidized or contaminated surface layer to expose the clean and fresh copper underneath.



The machine typically consists of a rotating drum or wheel that holds the copper rod. The drum is equipped with cutting blades or abrasive materials that scrape or grind the surface of the rod as it rotates. The peeling action removes the unwanted surface layer, leaving behind a smooth and clean copper surface.



The machine is designed to handle different sizes and lengths of copper rods. It can be operated manually or automated, depending on the specific model. Some advanced machines may also include features such as adjustable peeling depth, speed control, and safety mechanisms.

Soild Brass Rod Peeling Machine 18.5kw 25.8m/min Automatic Operation

Soild Brass Rod Peeling Machine 18.5kw 25.8m/min Automatic OperationSoild Brass Rod Peeling Machine 18.5kw 25.8m/min Automatic OperationSoild Brass Rod Peeling Machine 18.5kw 25.8m/min Automatic OperationSoild Brass Rod Peeling Machine 18.5kw 25.8m/min Automatic Operation



FAQ

1.COULD YOU ARRANGE THE ENGINEER FOR INSTALLATION AND COMMISSIONING?

A:Obviously yes,but the buyer pay the charges.



2.HOW TO CHOOSE ROD PEELING MACHINE?

A:It depends on your rod size,shape..etc.(Contact us for the details)



3.DO YOU PROVIDE ANY SPARE PARTS WITH THE MACHINE?

A:Yes,we will provide some common parts for you according to our packing list(cotact us for packing list)



4.WHAT IS THE DELIVERY PERIOD AFTER PLACING THE ORDER?

A:Normally 20-25days after deposit..



5.WHAT IS THE WARRANTY PERIOD AND AFTER-SERVICE FOR YOUR MACHINE?

A:1 year warranty for components and life-long technical supports(details depends on the warranty rules)
